Roberts 526 Big Bore CSX1244 Shelby Motor 2017-2018
4.375 Stroke x 4.375 Bore a 6.535″ Rods
Scat Billet Crank, Oliver Rods, Arias Pistons
See Below for more Details
2/1/17 Crankshaft Order Placed and deposit sent
Arias Piston order emailed to Nancy 1/31/17 – waiting for confirmation
Arias-Piston-Order-Form-1-31-17-Gessford Pistons received 3/16/17
Oliver Rods ordered 2/1/17 12:20 PM Factory direct 3 weeks Received 2/7/17
Gallery of Progress
-
- Oliver Rods 2/7/17
-
- Arias Pistons Mar 2017
-
- Rear Seal Knurl
-
- Billet Crank
Ready to start initial assembly 7/7/17
-
- Innovators West Dampner
-
- ATI SFI approved Flex Plate Internal Balance
-
- Balance Card
Robert sending Starter, Valve Covers and Starter soon 1/9/18
Neil on assemble this week of 1/6/18
-
- assembly images 1/11/18
-
- Head Gaskets received
-
- Crank in block – assembly 2-13-18
Two boxes received from Robert – Water Pump and Starter – Valve Cover to follow.
-
- Assembly 2/15/18 updates
Pressure checked Intake manifold 2/21/18 (OK) Bert
-
- PC Intake Manifold setup
Pressure checked both heads 2/21/18 (OK, OK) Tony (sorry no images of Tony doing this one)
-
- Smith Brothers Puchrods received
-
- Dummy Assembly
-
- 3/2/18
-
- 3/15/18 Images for Robert
Robert-B-First-Run-5-7-18-5689
2/9/2024 starter images
